COD ORIGINAL: 745746M91, 745747M91, 745760M91, 745760Z91, 81583, 83388, 86785, 92463, 92464, 41158025, 41158026, 41158026T, 41158041, 133588, 138123, 354.222.90.08, 3542229008, 357295, 3640232M1, 41158026, 41158053, 423614, 735648M91, 736329M91, 736432M91, 744207M91, 745749M91, 745760Z91, 7701202420, 86701, 86776, 922303.0001, 922303.0003, 922303.0010, 9223030001, 9223030003, 9223030010, 92464, P41158026, P41158029, P41158041, PER41158026, PER41158041, S40423, 02-101438, 02/101438, 02101438, 1055208001, 107 333, 107333, 133586, 08-107200-00, 800016211000, 34-12,


DATE TEHNICE:

Ø: 98.48 mm


SE POTRIVESTE LA:

Massey Ferguson

Tractor
Serie: 100
168 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 168F (Later blocks 104.20mm bore Ï, Liner without flame ring ), 168S (Early blocks 103.19mm bore Ï, Liner with flame ring ), 174 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 174C (Later blocks 104.20mm bore Ï, Liner without flame ring ), 174F (Early blocks 103.19mm bore Ï, Liner with flame ring ), 174S (Later blocks 104.20mm bore Ï, Liner without flame ring ), 174V (Early blocks 103.19mm bore Ï, Liner with flame ring ), 175 (Early blocks 103.19mm bore Ï, Liner with flame ring ), 175S (Early blocks 103.19mm bore Ï, Liner with flame ring ), 184 (Later blocks 104.20mm bore Ï ), 184F (Later blocks 104.20mm bore Ï, Liner without flame ring ), 184S (Early blocks 103.19mm bore Ï, Liner with flame ring ),

Serie: 1000
1014 (5 ring piston ), 1024 (5 ring piston ), 1100 (Std ring set ), 1104 (Std ring set ), 1114 (5 ring piston ), 1130, 1200 (5 ring piston ),

Serie: 1200
1250 (5 ring piston ),

Serie: 200
255 (USA) (Later blocks 104.20mm bore Ï, Liner without flame ring ), 265 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 273 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 274 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 274C (Early blocks 103.19mm bore Ï, Liner with flame ring ), 274CF (Early blocks 103.19mm bore Ï, Liner with flame ring ), 274S (Later blocks 104.20mm bore Ï, Liner without flame ring ), 274SK (Early blocks 103.19mm bore Ï, Liner with flame ring ), 275 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 275E (Later blocks 104.20mm bore Ï, Liner without flame ring ), 283 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 284 (Later blocks 104.20mm bore Ï ), 284S (Early blocks 103.19mm bore Ï ),

Serie: 200 (Brasil - South Africa)
265 (Later blocks 104.20mm bore Ï, Liner without flame ring ),

Serie: 2600
2620 (-> U653769H ), 2625 (-> U653769H ), 2640 (5 ring piston ), 2645 (5 ring piston ), 2675 (5 ring piston ),

Serie: 300
362 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 362N (Later blocks 104.20mm bore Ï, Liner without flame ring ), 365 (Early blocks 103.19mm bore Ï, Liner with flame ring ), 367CF (Early blocks 103.19mm bore Ï, Liner with flame ring ), 372N (Later blocks 104.20mm bore Ï, Liner without flame ring ), 373 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 373LX (Early blocks 103.19mm bore Ï, Liner with flame ring ), 373S (Later blocks 104.20mm bore Ï, Liner without flame ring ), 374AP (Later blocks 104.20mm bore Ï, Liner without flame ring ), 374AP(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ), 374AQ (Early blocks 103.19mm bore Ï, Liner with flame ring ), 374F (Early blocks 103.19mm bore Ï, Liner with flame ring ), 374FP (Early blocks 103.19mm bore Ï, Liner with flame ring ), 374FP(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ), 374FQ (Later blocks 104.20mm bore Ï, Liner without flame ring ), 374GE (Early blocks 103.19mm bore Ï, Liner with flame ring ), 374GE(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ), 374H (Early blocks 103.19mm bore Ï, Liner with flame ring ), 374S (Early blocks 103.19mm bore Ï, Liner with flame ring ), 374SP (Early blocks 103.19mm bore Ï, Liner with flame ring ), 374SP(X) (Later blocks 104.20mm bore Ï, Liner without flame ring ), 374SQ (Early blocks 103.19mm bore Ï, Liner with flame ring ), 374V (Later blocks 104.20mm bore Ï, Liner without flame ring ), 374VQ (Early blocks 103.19mm bore Ï, Liner with flame ring ), 375 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 375E (Later blocks 104.20mm bore Ï, Liner without flame ring ), 376C (Later blocks 104.20mm bore Ï, Liner without flame ring ), 376CF (Early blocks 103.19mm bore Ï, Liner with flame ring ), 376XCF (Early blocks 103.19mm bore Ï, Liner with flame ring ), 377 (Early blocks 103.19mm bore Ï, Liner with flame ring ), 383 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 383LX (Early blocks 103.19mm bore Ï, Liner with flame ring ), 383S (Early blocks 103.19mm bore Ï, Liner with flame ring ), 384AP (Early blocks 103.19mm bore Ï, Liner with flame ring ), 384AP(X) (Later blocks 104.20mm bore Ï, Liner without flame ring ), 384AQ (Early blocks 103.19mm bore Ï, Liner with flame ring ), 384F (Early blocks 103.19mm bore Ï, Liner with flame ring ), 384FP (Later blocks 104.20mm bore Ï, Liner without flame ring ), 384FP(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ), 384FQ (Early blocks 103.19mm bore Ï, Liner with flame ring ), 384GE (Early blocks 103.19mm bore Ï, Liner with flame ring ), 384GE(X) (Later blocks 104.20mm bore Ï, Liner without flame ring ), 384S (Early blocks 103.19mm bore Ï, Liner with flame ring ), 384SP (Early blocks 103.19mm bore Ï, Liner with flame ring ), 384SP(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ), 384SQ (Early blocks 103.19mm bore Ï, Liner with flame ring ), 384V (Later blocks 104.20mm bore Ï, Liner without flame ring ), 384VQ (Early blocks 103.19mm bore Ï, Liner with flame ring ), 387 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 399 (5 ring piston ),

Serie: 3000
3050 (Early blocks 103.19mm bore Ï, Liner with flame ring ), 3080 (5 ring piston ), 3090 (5 ring piston ),

Serie: 3200-3300
3220AP(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ), 3220FP(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ), 3220GE(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ), 3220SP(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ), 3225AP(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ), 3225FP(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ), 3225GE(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ), 3225SP(X) (Early blocks 103.19mm bore Ï, Liner with flame ring ),

Serie: 3600
3610 (5 ring piston ),

Serie: 500
565 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 575 (Early blocks 103.19mm bore Ï, Liner with flame ring ),

Serie: 600
675 (Early blocks 103.19mm bore Ï, Liner with flame ring ), 699 (5 ring piston ),

Industrial tractor
Serie:
30D (Later blocks 104.20mm bore Ï, Liner without flame ring ), 50 (Early blocks 103.19mm bore Ï, Liner with flame ring ), 50B, 50B MKII (Early blocks 103.19mm bore Ï, Liner with flame ring ), 50C (Early blocks 103.19mm bore Ï, Liner with flame ring ), 50D (Later blocks 104.20mm bore Ï, Liner without flame ring ), 50E (Early blocks 103.19mm bore Ï, Liner with flame ring ), 50H (Early blocks 103.19mm bore Ï, Liner with flame ring ), 50H-S (Later blocks 104.20mm bore Ï, Liner without flame ring ), 50H-T (Later blocks 104.20mm bore Ï, Liner without flame ring ), 60 (Early blocks 103.19mm bore Ï, Liner with flame ring ),

Combine-harvester
Serie:
10 Plot (Early blocks 103.19mm bore Ï, Liner with flame ring ), 16 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 16 Plot (Early blocks 103.19mm bore Ï, Liner with flame ring ), 187 (Early blocks 103.19mm bore Ï, Liner with flame ring ), 206 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 24 (Early blocks 103.19mm bore Ï, Liner with flame ring ), 240 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 307 (Later blocks 104.20mm bore Ï, Liner without flame ring ), 330 (Early blocks 103.19mm bore Ï, Liner with flame ring ), 500 (5 ring piston ), 507 (5 ring piston ), 510 (5 ring piston ), 515 (5 ring piston ), 520 (5 ring piston ), 525 (5 ring piston ), 530 (5 ring piston ), 530S (5 ring piston ), 535 (5 ring piston ), 8 Plot (Early blocks 103.19mm bore Ï, Liner with flame ring ), 800 (5 ring piston ), 805 (5 ring piston ), 810 (5 ring piston ), 815 (5 ring piston ), 99 (Later blocks 104.20mm bore Ï, Liner without flame ring ),


Landini

Tractor
Serie: 30
6530F, 6530L, 6530V, 6830, 7530F, 7530L, 7830,

Serie: 40
6840,

Serie: 50
6550, 7550,

Serie: 500
6500, 7500, 9500,

Serie: 505
7505,

Serie: 60
6560F, 6560L, 6560V, 68CV, 7560F, 7560L, 7860HC,

Serie: 60 NG
6860, 7860,

Serie: 70
6870, 7870, 78CV,

Serie: 80
6880, 6880VM, 7880, 7880VM,

Serie: Advantage
65F, 65FP, 65GE, 65GT, 65GTP, 65L, 65LP, 75F, 75FP, 75GE, 75GT, 75GTP, 75L, 75LP,

Serie: Blizzard
Blizzard 65, Blizzard 75,

Serie: Cingolati
C6030F, C6500, C6830, CF6830,

Serie: Large
10000,

Serie: Trekker
C75, CF65, CF70, CF75,

Serie: Vigneti Footstep
Vigneti 65V, Vigneti 75V,

Serie: Vigneti Rex cab
Vigneti 65V,

Serie: Vigneti Rex cab Tier2
Vigneti 75V,


Volvo

Tractor
Serie:
2200, 2204, 2250, 2254, 500,


JCB

520
520-2 (LD), 520-2HL (LD), 520-4 (LD), 520-4HL (LD), 520M-2 (LD), 520M-4 (LD), 520S (LD),

525
525-2 (LD), 525-4 (LD), 525B-2 (LD), 525B-2HL (LD), 525B-4,

530
530-2 (LD), 530-2HL (LD), 530-4 (LD), 530-4HL (LD), 530B-2, 530B-4 (LD), 530BHL-2 (LD), 530BHL-4 (LD),

540
540B2, 540B4 (LD), 540BM2, 540BM4 (LD),


Claas

Dominator 6
56,

Dominator 8
38, 38 S, 48, 48 S, 58 S, 68 S, 78 S, 88 S, 98 S,


TIP MOTOR:

A4.236 - Maxion Intl. Brasil
AT3.152.4 - Perkins
A6.354.1 - Perkins
A6.354 - Perkins
A4.236 - Perkins
A6.354.4 - Perkins
AD3.152 - Perkins
A4.212 - Perkins
AT6.354 - Perkins
D39T - Volvo-BM
